Stainless Steel Square Bottle Automatic Liquid Filler And Capping Machine With Accuracy

Product Description:

The capping method of this machine is six groups of capping units controlled by Delta servo motors from China. Each group is controlled by servo motors individually, with a three-jaw capping head. The bottle cap can be unscrewed in the reverse direction and screwed on in the forward direction, ensuring that the caps are tightly sealed.

The machine is equipped with a touch screen from Fuji, Japan, that makes it easy to operate. The touch screen interface is user-friendly and allows for easy control of the machine's functions.

The capping torque control of each capping unit is controlled by a servo motor, and the capping torque of the servo motor is preset. When capping, if the preset capping torque is not reached, the servo motor will automatically tighten the cap to the preset torque. This ensures that the caps are tightly sealed, and that there is no leakage of the cell culture media during transportation or storage.

The security features of the machine include SS304+ tempered glass, alarm information, door open shutdown, and an emergency stop device. These features ensure that the machine is safe to operate, and that there are no accidents during the filling and capping process.

In summary, the Media Filling Machine is a highly efficient and advanced piece of equipment that is perfect for industries that require large-scale production of cellular culturing medium. Its six groups of capping units, controlled by Delta servo motors, ensure that the caps are tightly sealed, and the touch screen interface from Fuji makes it easy to operate. The machine's security features ensure that it is safe to operate, and that there are no accidents during the filling and capping process.

Features:

• Product Name: Media Filling Machine
• Bottle specification: 125ml And 500ml
• Materials in contact with liquids: Stainless Steel 316L, Polymer Material For Medicine
• PLC: Siemens From Germany
• Production line composition:
  • Square Bottle 6 Heads Filling And Capping Machine
  • Automatic Sleeve Labeling Machine
  • Automatic Heat Shrinking Machine
  • Double Side Labeling Machine
  • Automatic Bottle Collection Platform
• Filling nozzle lifting: A Set Of High-power Servo Motor Control

Cellular culture media filler, Cell culture media filler, Cellular culture medium filler

Technical Parameters:

This is a technical parameter table for the Cell culturing medium filling machine, Cellular culturing media filler, and Cell culture medium filling machine.

Applications:

The PERWIN PW-ZMGX660 is suitable for filling 125ml and 500ml bottles with culture medium. It features six groups of capping units controlled by servo motors, with each group individually controlled, allowing for accurate and efficient capping. The three-jaw capping head can unscrew the bottle cap in the reverse direction and screw it on in the forward direction.

The filling process is controlled by six sets of precision pump heads driven by servo motors. The filling volume can be set and adjusted on the touch screen. The machine uses SS304 and tempered glass for security and has an emergency stop device, door open shutdown, and alarm information for added safety.

The PERWIN PW-ZMGX660 has a compressed air requirement of 0.4~0.7Mpa. It comes packaged in export standard wooden cases and has a delivery time of 60 working days. Payment terms are TT, and the supply ability is 10pcs/month.

The PERWIN PW-ZMGX660 is ideal for use in research laboratories, biotech companies, and medical institutions that require precise and efficient filling of culture medium for cellular culturing. With its advanced technology and high-quality materials, this filling machine offers a reliable and safe solution for your filling needs.

Customization:

The production line composition includes Square Bottle 6 Heads Filling And Capping Machine, Automatic Sleeve Labeling Machine, Automatic Heat Shrinking Machine, Double Side Labeling Machine, and Automatic Bottle Collection Platform. The PLC used is Siemens from Germany. The bottle separating method is Reciprocating Bottle Feeding Module Driven By Servo Motor. Each Capping Unit Is Controlled By A Servo Motor, And The Capping Torque Of The Servo Motor Is Preset. When Capping, If The Preset Capping Torque Is Not Reached, The Servo Motor Will Automatically Tighten The Cap To The Preset Torque. The bottle specification is 125ml And 500ml.

To customize the Cellular culture medium filler to meet your specific needs, please contact PERWIN.

Packing and Shipping:

Product Packaging:

The Media Filling Machine will be packaged in a sturdy cardboard box with foam padding to ensure safe transport. The product will be disassembled and placed inside the box, along with the necessary tools and instructions for assembly. The box will be labeled with the product name, company logo, and handling instructions.

Shipping:

The Media Filling Machine will be shipped via a reputable courier service, such as UPS or FedEx, to the address provided by the customer. Shipping costs will be calculated based on the destination and weight of the package. The customer will be provided with a tracking number to monitor the delivery status of their package.
