Product Details
Place of Origin: Shanghai
Brand Name: PERWIN
Certification: CE, ISO, GMP, UL, TUV, SGS
Model Number: PW-ZWGX550
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Export Standard Wooden Cases
Delivery Time: 60 working days
Payment Terms: TT
Supply Ability: 10pcs/month
Filling Program Control: |
Each Group Of Pumps Is Individually Controlled |
Bottle Separating Method: |
1 Set Of Servo Motor Drive Screw For Positioning |
Rejection Unit: |
Automatic Reject Workstation, Conveyor Belt Controlled By Servo Motor. Corresponds To A Group Of 5 Bottles, Each Bottle Corresponds To A Cylinder. Unqualified Bottles Can Be Pushed Into The Corresponding Channel Of The Collection Platform With The Correspo |
Buffer Bag: |
Single Use Buffer Bag With Pipes And Filling Nozzles |
Security: |
304 Stainless Steel Frame, Tempered Glass Cover. Open The Door To Stop; Emergency Stop Device, Earth Leakage Protection. HEPA Can Be Installed |
Weight: |
1000kg |
Filling Environment: |
Aseptic Filling Environment, A-class(ISO5) 100 Laminar Flow Hood Is Required |
Working Process: |
Bottle Loading On Powered Platform (unpacking Station)→ Screw Positioning Bottle → De-capping → Weighing I → Peristaltic Pump Filling→ Weighing II And Capping→Automatic Rejection Station→Finished Products To Packing Area→ Automatic Sleeve Labeling → Heat S |
Filling Program Control: |
Each Group Of Pumps Is Individually Controlled |
Bottle Separating Method: |
1 Set Of Servo Motor Drive Screw For Positioning |
Rejection Unit: |
Automatic Reject Workstation, Conveyor Belt Controlled By Servo Motor. Corresponds To A Group Of 5 Bottles, Each Bottle Corresponds To A Cylinder. Unqualified Bottles Can Be Pushed Into The Corresponding Channel Of The Collection Platform With The Correspo |
Buffer Bag: |
Single Use Buffer Bag With Pipes And Filling Nozzles |
Security: |
304 Stainless Steel Frame, Tempered Glass Cover. Open The Door To Stop; Emergency Stop Device, Earth Leakage Protection. HEPA Can Be Installed |
Weight: |
1000kg |
Filling Environment: |
Aseptic Filling Environment, A-class(ISO5) 100 Laminar Flow Hood Is Required |
Working Process: |
Bottle Loading On Powered Platform (unpacking Station)→ Screw Positioning Bottle → De-capping → Weighing I → Peristaltic Pump Filling→ Weighing II And Capping→Automatic Rejection Station→Finished Products To Packing Area→ Automatic Sleeve Labeling → Heat S |
The weighing unit of the Fetal bovine serum filling machine consists of a Mettler Load Cell + Controller. The machine is designed to be installed on a marble floor foundation, ensuring that it remains stable and reliable during use. The load cell ensures accurate measurement of the weight of the serum being filled, while the controller allows for precise control of the filling process.
The FBS filling machine is capable of filling 5~30 bottles per minute, making it highly efficient and ideal for high-volume laboratories and research facilities. The machine is equipped with a single-use buffer bag with pipes and filling nozzles, ensuring that the serum is filled in a completely sterile environment.
The Animal Serum Filler is equipped with five, six, seven or eight filling nozzles, depending on the specific requirements of the user. This allows for flexibility in the types of bottles that can be filled, and ensures that the machine can meet the specific needs of each user.
Our Animal Sera filling line is built with high-quality materials and is perfect for filling animal serum and blood products. Our Animal Serum Filling Equipment is designed to fill bottles quickly and efficiently, with a filling speed of 5~30bottles/min. The Animal Blood Filling Machine is made of stainless steel and has a filling pressure of 0-0.3Mpa, ensuring that the filling process is accurate and consistent. The Automatic Reject Workstation and Conveyor Belt Controlled By Servo Motor guarantee that unqualified bottles are separated from the rest, making sure that only the highest quality products are delivered to your customers.
| Product Name | Animal Serum Filling Equipment |
| Material | Stainless Steel |
| Filling Environment | Aseptic Filling Environment, A-class(ISO5) 100 Laminar Flow Hood Is Required |
| Weight | 1000kg |
| Filling Program Control | Each Group Of Pumps Is Individually Controlled |
| Bottle Separating Method | 1 Set Of Servo Motor Drive Screw For Positioning |
| Filling Accuracy | ±0.5~1% |
| Power Supply | 220V/380V/415V/440V |
| Power Consumption | 10KW For Whole Line |
| PLC | Siemens 1500 |
| Working Process | Bottle Loading On Powered Platform (unpacking Station)→ Screw Positioning Bottle → De-capping → Weighing I → Peristaltic Pump Filling→ Weighing II And Capping→Automatic Rejection Station→Finished Products To Packing Area→ Automatic Sleeve Labeling → Heat Shrinking Machine → Single Side Labeling Machine→Bottle Collection Platform |
| Product Type | Animal Plasma Aseptic Filling Line, Animal Sera Aseptic Filling Device |
With a 304 stainless steel frame and tempered glass cover, this machine is built to last. It also features an emergency stop device, earth leakage protection, and the option to install a HEPA filter for added security. The capping head lift is controlled by a servo motor, ensuring consistent and precise sealing of the filled vials.
For environmental monitoring, the machine comes with an online particle and planktonic monitoring system, which ensures that the filling process is carried out in a clean and sterile environment. The filling accuracy is ±0.5~1%, and the machine can be equipped with five, six, seven, or eight filling heads, depending on your needs.
PERWIN's PW-ZWGX550 Animal Serum Filling Machine has been certified by CE, ISO, GMP, UL, TUV, and SGS, ensuring that it meets the highest standards of quality and safety. It comes in export standard wooden cases and has a minimum order quantity of one. The price is negotiable, and the delivery time is 60 working days. Payment terms are TT, and the supply ability is 10pcs/month.
So, whether you're in the business of producing animal sera for research purposes or need a reliable machine for your laboratory, PERWIN's PW-ZWGX550 Animal Serum Filling Machine is the perfect choice for you. Contact us today to learn more or to place an order.
The Animal Sera Filling Machine is designed to fill animal sera into vials or bottles for laboratory use. Our technical support team is available to assist with any questions or issues you may encounter with the machine. We offer the following services:
Our goal is to ensure that your Animal Sera Filling Machine operates efficiently and reliably, so that you can focus on your research and testing needs.
A: The brand name of this animal sera filling machine is PERWIN.
Q: What is the model number of this animal sera filling machine?
A: The model number of this animal sera filling machine is PW-ZWGX550.
Q: Where is this animal sera filling machine manufactured?
A: This animal sera filling machine is manufactured in Shanghai.
Q: What certifications does this animal sera filling machine have?
A: This animal sera filling machine is certified with CE, ISO, GMP, UL, TUV, and SGS.
Q: What is the minimum order quantity for this animal sera filling machine?
A: The minimum order quantity for this animal sera filling machine is 1.
Q: What is the price of this animal sera filling machine?
A: The price of this animal sera filling machine is negotiable.
Q: What are the packaging details for this animal sera filling machine?
A: The packaging details for this animal sera filling machine are export standard wooden cases.
Q: What is the delivery time for this animal sera filling machine?
A: The delivery time for this animal sera filling machine is 60 working days.
Q: What are the payment terms for this animal sera filling machine?
A: The payment terms for this animal sera filling machine are TT.
Q: What is the supply ability for this animal sera filling machine?
A: The supply ability for this animal sera filling machine is 10pcs/month.
