2000BPH Enzyme Plastic Automatic Tube Filling Machine Pneumatic Driven

liquid filling line manufacturers filling machine usa for enzyme 5ml

1. Brief introduction.

This reagent filling machine  adopt the advanced working principal, mechanical and electrical design, and has reliable and stable performance, which is suitable for filling of different liquid oral formulations, such as syrups, suspensions, soft extract, tincture and mixture etc.

2. Features.

1. The bottle entering mode can be in different scheme based on the user’s requirement and bottle shape feature.
2. Adopting 316L stainless steel piston cylinder, and ceramic plunger type cylinder or designated method by user for precision filling, the filling accuracy is ±0.5~1%
3. The function of automatic alarm and stop when filling needles deviate from bottle neck.
4. The unique inlet and outlet check valve and the precision machining to ensure not dropping when filling. The filling needle will move up and down or submersible filling, to prevent liquid bubbling or splashing.
5. The specially designed lid and lid feeding matched automatic precisely up with capping, accurately complete each mechanical motion cycle, such as crabbing lid, capping, and others, the whole process in unison, stably and reliably, without dropping lid.
6. The specially designed torque limiter, flexible connection pressure rotary buffer mechanism and individualized screw capping scheme to keep the capping torsion stable not to damage the lid and the Stability and reliability for the capping quality.
7. Have the function of online automatic removing when no lid. (Optional by customer)
8. The whole production line of intelligent control has the function of chain control for upstream and downstream working equipment.

9. The surface of main parts of the whole production line is made of SUS 304 stainless steel, hardness of anodized aluminum alloy, non-toxic polymeric materials, etc. which comply with GMP rules.
